1PCS OLED LCD Display Module, 0.91" 4 Wire SPI Serial OLED Screen Driver,128x32 3.3V ~ 4.2V for Ledger Nano S (12Pin Blue Light, 1pcs)
4.2 (55 items)
Limited Time Sale$5.34 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 239535590 | Release Date | 2026/07/14 | List Price | $3.56 | Model Number | 239535590 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Features:OLED display, no need backlight, self-illumination.The display performance is better than the traditional LCD display, also lower consumption.Specifications:Diagonal Screen Size:0.91inchModule Construction:COGNumber of Pixels:128X32Active Area:22.384x5.584mmPanel Size:30x11.5x1.2mmPins:12Drive IC:SSD1306Interface:I2COLED Applications:Can be applied to Card Reader,USB Key,Router,Set-Top Box ,Car Audio,Timer,Glucose Meter,Thermometer ,Remote Controller, Digital Camera, Game Machine, E-Cigarette,etc.Nano S：There are two different versions for the displays that use on Nano S, please open the housing and check the FPC (flex cable) width before purchasing.
- 【Display performance】The 0.91 oled I2c display,Blue display color,the display performance is better than the traditional LCD display, also lower consumption，no backlight required, self-illumination.
- 【OLED Resolution】 128x32，3.3 ~ 4.2V power supply; Operating temperature: -40 ~ 80 ℃，Display controller: SSD1306, Signal interface: 4 wire SPI Pitch 4-pin，High Contrast Ratio (10,000:1)
- 【OLED Benefits】 Compact design makes it easy to carry anywhere.Thinner & Lighter & Durable，Free Viewing Angle，Fast Response Time (≤15μs).
- 【Applicable To】 Such as industrial POS & Server，USB Key，Card Reader and Communication Router，Set-Top Box Mobile Phone，Most Products from Any Segment.
- 【Nano S】There are two different versions for the displays that use on Nano S, please open the housing and check the FPC (flex cable) width before purchasing.
| UPC | 768365627408 |
|---|---|
| ASIN | B0FM7BBBF2 |
| Color | blue |
| Model | 15PinWhite6pc |
| Brand Name | elecsung |
| Unit Count | 1.0 Count |
| Part Number | 15PinWhite2pc |
| Manufacturer | elecsung |
| Material Type | Plastic |
| Mounting Type | Panel Mount |
| Connector Type | IDC |
| Number Of Poles | 12 |
| Specification Met | CE |
| Number Of Contacts | 2 |
| Included Components | oled display |
| Number of Positions | 2 |
| Item Dimensions W x H | 3.5"W x 2.3"H |
| Upper Temperature Rating | 80 Degrees Celsius |
